Xerox Phaser 3610 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-19
Status Code List (3610)
Note: Be aware that the error code that shows up on the UI for some errors does not have the
same chain link code that will be displayed in the Error History report.
Note: When the LCD Message column displays ‘-’, ’xxxxxxxx’, the LCD doesn’t display any
messages (it displays only the Status code), the error is dealt with internally. When the LCD
Message column displays ’xxxxxxxx Duplicate IPv6 Add….’, the LCD doesn’t display any
messages (displays only the Status code).
Status
Code
(3610)
LCD Message Name/Description of Error FIP
004-310
Reseat Feeder
Power Off/On
Error 004-310
Power Off/On
<IOT Option Feeder I/F Failure>
Cause:
The Option Feeder communication failure is
detected.
FIP 1. 01
010-317
Insert Fuser
010-317
Insert Fuser
Power Off/On
<FUSING ASSEMBLY Detached>
Cause:
FUSING ASSEMBLY detached is detected.
FIP 1. 04
010-397
Fuser Error
Power Off/On
Error 010-397
Power Off/On
<FUSING ASSEMBLY Failure>
Cause:
The operation error of FUSING ASSEMBLY
(Temperature anomaly error etc.) is detected.
FIP 1. 04
016-338
Reseat Wi-Fi
Contact Admin.
Error 016-338
Power Off/On
<Wireless Option Error>
Cause:
Wireless Driver starting error.
FIP 1. 08
016-359
MRAM Error
Power Off/On
Error 016-359
Power Off/On
<MRAM Fail>
Cause:
MRAM Device Error.
FIP 1. 09
016-369
Error 016-369
Power Off/On
<UI Panel - ESS Communication Fail>
Cause:
Communication Fail with a UI Panel and ESS F/W.
FIP 1. 10

Xerox Phaser 3610 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Maximum duty cycle	110000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Network ready	Yes
Security algorithms	EAP, EAP-TLS, EAP-TTLS, WPA-PSK, WPA2-PSK
Mobile printing technologies	Apple AirPrint
Internal memory	512 MB
Processor frequency	400 MHz
Maximum internal memory	1024 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper
Paper tray media weight	60 - 216 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet
Optional connectivity	Wireless LAN
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (standby)	52 W
Power consumption (printing)	686 W
Power consumption (PowerSave)	2 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 28 °C
Operating relative humidity (H-H)	20 - 70 %
Product color	Blue, White

Weight and Dimensions

Depth	426 mm
Width	393 mm
Height	315 mm
Weight	13000 g
