Xerox Phaser 3610

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-323
FIP 2.10
Registration Clutch Assembly
Cause:
Parts to be considered:
•MAIN DRIVE ASSEMBLY (PL 4.1 Drive)
• REGISTRATION CLUTCH (REP 5.6 MCU PWB)
•MCU PWB (PL 5.3 Electrical (MCU PWB / HVPS))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the REGI.
CLUTCH Drive Section?
Remove the for-
eign substances
Go to Step 2.
2
Is the MAIN DRIVE ASSEMBLY damaged?
Replace
(REP 4.1 Main
Drive Assembly)
Go to Step 3.
3
Check the connection between the REGI.
CLUTCH and the MCU PWB.
• Is the REGI. CLUTCH (P/J12) connected
securely?
Go to Step 4.
Securely con-
nect the REGI.
CLUTCH
4
•Replace (REP 2.6 Registration Clutch)
Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.
