Xerox Phaser 3610

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-125
Error Code Fault Isolation Procedures (FIP)
FIP 1. 01
004-310 IOT Option Feeder I/F Failure
Cause:
The Option Feeder communication failure is detected.
Solution:
Turn the power Off and On to check that the error recurs, then proceed to the FIP.
Step Check and Action Yes No
1
• Check the connections between the OPTIONAL
TRAY PWB ASSEMBLY and the MCU PWB, as well
as between the OPTIONAL TRAY PWB ASSEMBLY
and the LVPS PWB.
• Are the OPTIONAL FEEDER HARNESS ASSEMBLY
and the FEEDER HARNESS ASSEMBLY DRAWER 1
connected securely?
Go to Step 2.
Securely connect
the OPTIONAL
FEEDER HARNESS
ASSEMBLY and
the FEEDER HAR-
NESS ASSEMBLY
DRAWER 1
2
• Replace the OPTIONAL FEEDER HARNESS
ASSEMBLY.
• Does an error occur?
Go to Step 3.
Troubleshooting
complete.
3
• Replace the FEEDER HARNESS ASSEMBLY
DRAWER 1.
• Does an error occur?
Go to Step 4.
Troubleshooting
complete.
4
•Replace (REP 7.5 Optional Tray PWB Assembly).
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.
