Xerox Phaser 3610

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-322
FIP 2.09
Invert Clutch Assembly
Cause:
Parts to be considered:
• DRIVE EXIT OUT HOLDER ASSEMBLY (PL 4.1 Drive)
• DRIVE EXIT IN HOLDER ASSEMBLY (PL 4.1 Drive)
• INVERT CLUTCH ASSEMBLY (PL 4.1 Drive)
•MCU PWB (PL 5.3 Electrical (MCU PWB / HVPS))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the
INVERT CLUTCH ASSEMBLY Drive Sec-
tion?
Remove the foreign
substances
Go to Step 2.
2
Is the DRIVE EXIT OUT HOLDER ASSEM-
BLY or the DRIVE EXIT IN HOLDER
ASSEMBLY damaged?
Replace the DRIVE
EXIT OUT HOLDER
ASSEMBLY and the
DRIVE EXIT IN
HOLDER ASSEMBLY
Go to Step 3.
3
Check the connection between the
INVERT CLUTCH ASSEMBLY and the
MCU PWB.
• Is the INVERT CLUTCH ASSEMBLY
(P/J17) connected securely?
Go to Step 4.
Securely connect
the INVERT-
CLUTCH ASSEM-
BLY
4
• Replace the INVERT CLUTCH
ASSEMBLY.
• Does an error occur?
Replace
(REP 5.6 MCU PWB)
Troubleshooting
complete.
