Xerox Phaser 3610

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-335
FIP 2.21
DC Power FIP
Cause:
Parts to be considered:
•CONTROL PANEL (PL 1.4 Control Panel (3610) / PL 1.5 Control Panel (3615))
• ESS PWB (PL 5.1 Electrical (ESS PWB / LVPS) (3610) / PL 5.2 Electrical (ESS PWB / LVPS)
(3615))
•LVPS (PL 5.1 Electrical (ESS PWB / LVPS) (3610) / PL 5.2 Electrical (ESS PWB / LVPS)
(3615))
•MCU PWB (PL 5.3 Electrical (MCU PWB / HVPS))
Solution:
Step Check and Action Yes No
1
• Check the connection of the LVPS PWB
connectors
• Remove the Power Cord and wait for one
minute.
• Reinstall all of the connectors on the LVPS
PWB.
• Does the device operate?
Troubleshooting
complete. Go to Step 2.
2
• Reinstall the CONTROL PANEL
connectors. (REP 1.1 Control Panel
(3610)) (REP 1.12 Control Panel (3615))
• Does the device operate?
Troubleshooting
complete. Go to Step 3.
3
• Reinstall (REP 5.1 ESS PWB).
• Does the device operate?
Troubleshooting
complete. Go to Step 4.
4
• Reinstall (REP 5.6 MCU PWB).
• Does the device operate?
Troubleshooting
complete.
Replace
(REP 5.3 LVPS)
