Wiring
Phaser 3610, WorkCentre 3615 Service Manual7-4
Plug/Jack Locations for the 3615
P/J (3615) Illustration Description
1 Illustration 07 Connects USB PWB to ESS PWB
2 Illustration 07 Connects USB PWB to Control Panel
10 Illustration 08 Connects MCU PWB and MAIN MOTOR HARNESS ASSY
11 Illustration 08 Connects MCU PWB and DISP MOTOR HARNESS ASSY
12 Illustration 08 Connects MCU PWB and REGI CLUTCH
13 Illustration 08 MCU PWB (not used)
14 Illustration 08 Connects MCU PWB and CST FEED CLUTCH
15 Illustration 08 Connects MCU PWB and MSI FEED SOLENOID
16 Illustration 08 Connects MCU PWB and EXIT CLUTCH ASSY
17 Illustration 08 Connects MCU PWB and INVERT CLUTCH ASSY
18 Illustration 08 Connects MCU PWB and ROS ASSY
19 Illustration 08 Connects MCU PWB and ROS-MCU HARNESS
20 Illustration 08 Connects MCU PWB and ESS HARNESS ASSY
21 Illustration 08 Connects MCU PWB and MCU HARNESS ASSY
22 Illustration 08 Connects MCU PWB and LVPS HARNESS ASSY
23 Illustration 08 Connects MCU PWB and FUSER HARNESS ASSY
24 Illustration 08 Connects MCU PWB and OP FDR HARNESS ASSY
25 Illustration 08 Connects MCU PWB and XERO CRUM HARNESS ASSY
26 Illustration 08 Connects MCU PWB and HVPS HARNESS ASSY
27 Illustration 08 Connects MCU PWB and EXIT SENSOR HARNESS ASSY
30 Illustration 08 MCU PWB (not used)
101 Illustration 10 Connects MAIN DRIVE ASSY and MAIN MOTOR HARNESS ASSY
111 Illustration 11 Connects DISP MOTOR and DISP MOTOR HARNESS ASSY
200 Illustration 07 Connects LVPS PWB and AC INLET
201 Illustration 07 Connects LVPS PWB and FUSER HARNESS ASSY
210 Illustration 07 Connects LVPS PWB and MCU HARNESS ASSY
211 Illustration 07 Connects LVPS PWB and ESS HARNESS ASSY
212 Illustration 07 Connects LVPS PWB and MAIN MOTOR HARNESS ASSY
213 Illustration 07 Connects LVPS PWB and OP FDR HARNESS ASSY
220 Illustration 07 Connects LVPS PWB and LVPS HARNESS ASSY
221 Illustration 07 Connects ESS PWB and SD CARD
230 Illustration 07 Connects LVPS PWB and INTLK HARNESS ASSY
