Xerox Phaser 3610

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-317
FIP 2.04
CST No Paper Sensor
Cause:
Parts to be considered:
• NO PAPER TRAY ACTUATOR (PL 2.2 Transport Assembly)
• CST NO PAPER TRAY SENSOR (PL 5.3 Electrical (MCU PWB / HVPS))
• HVPS HARNESS ASSEMBLY (PL 5.4 Electrical Connections)
•MCU PWB (PL 5.3 Electrical (MCU PWB / HVPS))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the CST NO
PAPER TRAY SENSOR HVPS DETECTOR?
Remove the for-
eign substances
Go to Step 2.
2
Is the NO PAPER TRAY ACTUATOR damaged?
Replace the NO
PAPER TRAY
ACTUATOR
Go to Step 3.
3
Check the connection between the HVPS and the
MCU PWB.
• Is the HVPS HARNESS ASSEMBLY(P/J261 -
P/J26) connected securely?
Go to Step 4.
Securely connect
the HVPS HAR-
NESS ASSEMBLY
4
• Replace the HVPS HARNESS ASSEMBLY.
• Does an error occur?
Go to Step 5.
Troubleshooting
complete.
5
•Replace (REP 5.7 HVPS (3610)) (REP 5.8
HVPS (3615))
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.
