Xerox Phaser 3610

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-320
FIP 2.07
Path Sensor
Cause:
Parts to be considered:
• PRE REGI-ACTUATOR (PL 7.4 Tray 1/Optional Tray 550-Sheet Feeder (4/4))
•PATH SENSOR (PL 7.4 Tray 1/Optional Tray 550-Sheet Feeder (4/4))
• OPTIONAL REGI HARNESS ASSEMBLY (PL 7.4 Tray 1/Optional Tray 550-Sheet Feeder
(4/4))
• OPTIONAL TRAY PWB ASSEMBLY (PL 7.1 Tray 1/Optional Tray 550-Sheet Feeder (1/4))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the PATH
SENSOR DETECTOR?
Remove the foreign
substances
Go to Step 2.
2
Is the PRE REGI-ACTUATOR damaged?
Replace the PRE
REGI-ACTUATOR
Go to Step 3.
3
Check the connection between the Path
Sensor & the OPTIONAL TRAY PWB ASSY.
• Is the OPTIONAL REGI HARNESS
ASSEMBLY (P/J4212 - P/J4214)
connected securely?
Go to Step 4.
Securely con-
nect the
Optional Regi
Harness
Assembly
4
• Replace the Path Sensor.
Does an error occur? Go to Step 5.
Troubleshooting
complete.
5
• Replace the OPTIONAL REGI HARNESS
ASSEMBLY.
Does an error occur? Replace the MCU
Troubleshooting
complete.
