Xerox Phaser 3610 Service Manual

Specifications
Phaser 3610, WorkCentre 3615 Service Manual 8-3
Functional Configuration
System Configuration for the 3615
IIT (Image Input Terminal):
• The IIT is a device to scan documents for copying, facsimile (FAX) sending, and scanning. The
IIT can scan documents with an optical resolution of 1200 dots/25.4mm and 1200
dots/25.4mm in the fast scan direction. The resolution in the slow scan direction is set based
on the scan speed and electrical resolution conversion.
• The IIT is equipped with the DADF (Duplex Automatic Document Feeder) as standard.
IOT (Image Output Terminal):
• The IOT writes video data from each portion on paper for copying, outputting files received
by the facsimile, and outputting from the printer. The Laser xerography technology engine
allows for image recording on paper up to 14 in. (355.6mm) length at 600 dots/25.4mm.
Operator Panel:
• The operator panel displays various settings, instructions, and error messages for copying,
sending a fax, scanning, and printing. It has touch sensor and buttons for user operations.
The operator panel is also referred to as just “Panel” in this specification.
Engine
Control Panel
2 Line Bitmap LCD Panel
SFP Controller
LM1
Option
࡮
Memory
࡮
SD-Card
ROS
IOT
IOT MCU
Network (Rear)
USB2.0 (Rear)
Wireless Network
(Option)
USB Host 2.0(Rear
）
ZaS06005XB
Option
࡮
550 Sheet Feeder

Xerox Phaser 3610 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Maximum duty cycle	110000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Network ready	Yes
Security algorithms	EAP, EAP-TLS, EAP-TTLS, WPA-PSK, WPA2-PSK
Mobile printing technologies	Apple AirPrint
Internal memory	512 MB
Processor frequency	400 MHz
Maximum internal memory	1024 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper
Paper tray media weight	60 - 216 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet
Optional connectivity	Wireless LAN
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (standby)	52 W
Power consumption (printing)	686 W
Power consumption (PowerSave)	2 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 28 °C
Operating relative humidity (H-H)	20 - 70 %
Product color	Blue, White

Weight and Dimensions

Depth	426 mm
Width	393 mm
Height	315 mm
Weight	13000 g
