Wiring
Phaser 3610, WorkCentre 3615 Service Manual7-2
Plug/Jack Locations
Plug/Jack Locations for the 3610
P/J (3610) Illustration Description
10 Illustration 02 Connects MCU PWB and MAIN MOTOR HARNESS ASSY
11 Illustration 02 Connects MCU PWB and DISP MOTOR HARNESS ASSY
12 Illustration 02 Connects MCU PWB and REGI CLUTCH
13 Illustration 02 MCU PWB (not used)
14 Illustration 02 Connects MCU PWB and CST FEED CLUTCH
15 Illustration 02 Connects MCU PWB and MSI FEED SOLENOID
16 Illustration 02 Connects MCU PWB and EXIT CLUTCH ASSY
17 Illustration 02 Connects MCU PWB and INVERT CLUTCH ASSY
18 Illustration 02 Connects MCU PWB and ROS ASSY
19 Illustration 02 Connects MCU PWB and ROS-MCU HARNESS
20 Illustration 02 Connects MCU PWB and ESS HARNESS ASSY
21 Illustration 02 Connects MCU PWB and MCU HARNESS ASSY
22 Illustration 02 Connects MCU PWB and LVPS HARNESS ASSY
23 Illustration 02 Connects MCU PWB and FUSER HARNESS ASSY
24 Illustration 02 Connects MCU PWB and OP FDR HARNESS ASSY
25 Illustration 02 Connects MCU PWB and XERO CRUM HARNESS ASSY
26 Illustration 02 Connects MCU PWB and HVPS HARNESS ASSY
27 Illustration 02 Connects MCU PWB and EXIT SENSOR HARNESS ASSY
30 Illustration 02 MCU PWB (not used)
101 Illustration 04 Connects MAIN DRIVE ASSY and MAIN MOTOR HARNESS ASSY
111 Illustration 05 Connects DISP MOTOR and DISP MOTOR HARNESS ASSY
200 Illustration 01 Connects LVPS PWB and AC INLET
201 Illustration 01 Connects LVPS PWB and FUSER HARNESS ASSY
210 Illustration 01 Connects LVPS PWB and MCU HARNESS ASSY
211 Illustration 01 Connects LVPS PWB and ESS HARNESS ASSY
212 Illustration 01 Connects LVPS PWB and MAIN MOTOR HARNESS ASSY
213 Illustration 01 Connects LVPS PWB and OP FDR HARNESS ASSY
220 Illustration 01 Connects LVPS PWB and LVPS HARNESS ASSY
220 Illustration 04 Connects CONSOLE ASSY and UI HARNESS ASSY
230 Illustration 01 Connects LVPS PWB and INTLK HARNESS ASSY
