Xerox Phaser 3610

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-314
Level 2 FIPs
FIP 2.01
Exit Sensor
Cause:
Parts to be considered:
•EXIT CHUTE ASSEMBLY (PL 2.5 Exit Chute)
•EXIT SENSOR (PL 2.5 Exit Chute)
• EXIT SENSOR HARNESS ASSEMBLY (PL 5.4 Electrical Connections)
•MCU PWB (PL 5.3 Electrical (MCU PWB / HVPS))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the EXIT
SENSOR Detector?
Remove the for-
eign substances
Go to Step 2.
2 Is the EXIT CHUTE ASSEMBLY damaged?
Replace
(REP 2.11 Exit
Chute Assem-
bly)
Go to Step 3.
3
Check the connection between the EXIT
SENSOR and the MCU PWB.
• Is the EXIT SENSOR HARNESS ASSEMBLY
(P/J271-P/J27) connected securely?
Go to Step 4.
Securely connect
the EXIT SENSOR
HARNESS ASSEM-
BLY
4
• Replace the EXIT SENSOR.
Does an error occur?
Go to Step 5.
Troubleshooting
complete.
5
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.
