Xerox Phaser 3610

Image Quality
Phaser 3610, WorkCentre 3615 Service Manual3-26
7
Adjust the voltage value of the Transfer Roller
Assembly by performing the Adjust Transfer Unit
(ADJ 2 Adjusting the Transfer Unit)
Is the image printed correctly?
Troubleshooting
complete.
Go to step 8.
8
Reseat the Drum Cartridge.
Is the image printed correctly?
Troubleshooting
complete.
Go to step 9.
9
Remove (REP 3.4 Transfer Roller Assembly).
Are the Plate Spring BTR on the HVPS dirty or
deformed?
Clean up the Plate
Spring BTR or replace
(REP 5.7 HVPS (3610) /
REP 5.8 HVPS (3615)),
then go to step 10.
Go to step 10.
10
Reseat (REP 3.4 Transfer Roller Assembly).
Is the image printed correctly?
Troubleshooting
complete.
Replace (REP 3.4
Transfer Roller
Assembly).
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
