Xerox Phaser 3610

Image Quality
Phaser 3610, WorkCentre 3615 Service Manual 3-29
9
Is the Drum Cartridge installed properly, with no
foreign substances at the contact point between
the ATC Sensor in the Drum Cartridge and the
Xerographic Connector Assembly?
Go to Step 10.
Reinstall the Drum Car-
tridge, then go to
step 10.
10
Is the connection terminal of the ATC Sensor part
in the Drum Cartridge damaged?
Replace the Drum Car-
tridge, then go to
step 11.
Go to Step 11.
11
Is the connection terminal of the Xerographic
Connector Assembly damaged?
Replace (REP 3.3
Xerographic Connector
Assembly) then go to
step 12.
Go to Step 12.
12 Is the image printed correctly?
Troubleshooting
complete.
Go to step 13.
13
Reseat the HVPS.
Is the image printed correctly?
Troubleshooting
complete.
Go to step 14.
14
Replace the Drum Cartridge.
Is the image printed correctly?
Troubleshooting
complete.
Replace (REP 5.7 HVPS
(3610) / REP 5.8 HVPS
(3615)).
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
