Xerox Phaser 3610

Image Quality
Phaser 3610, WorkCentre 3615 Service Manual3-34
8
Remove the Drum Cartridge.
Are the Spring BCR and Spring DB on the HVPS
dirty or deformed?
Clean up the Spring
BCR and Spring DB or
replace (REP 5.7 HVPS
(3610) / REP 5.8 HVPS
(3615)), then go to
step 9.
Go to step 9.
9
Reseat the Drum Cartridge.
Is the image printed correctly?
Troubleshooting
complete.
Go to step 10.
10
Replace (REP 3.4 Transfer Roller Assembly).
Is the image printed correctly?
Troubleshooting
complete.
Go to step 11.
11
Replace the Drum Cartridge.
Is the image printed correctly?
Troubleshooting
complete.
Go to step 12.
12
Replace (REP 3.5 Fusing Assembly).
Is the image printed correctly?
Troubleshooting
complete.
Go to step 13.
13
Replace (REP 3.1 ROS Assembly).
Is the image printed correctly?
Troubleshooting
complete.
Replace (REP 5.7 HVPS
(3610) / REP 5.8 HVPS
(3615)).
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
