Xerox Phaser 3610

Image Quality
Phaser 3610, WorkCentre 3615 Service Manual3-36
6
Is the Drum Cartridge installed properly, with no
foreign substances at the contact point between
the ATC Sensor in the Drum Cartridge and the
Xerographic Connector Assembly?
Go to Step 7.
Reinstall the Drum Car-
tridge, then go to
step 7.
7 Is the connection terminal of the ATC Sensor part
in the Drum Cartridge damaged?
Replace the Drum Car-
tridge, then go to
step 8.
Go to Step 8.
8
Is the connection terminal of the Xerographic
Connector Assembly damaged?
Replace (REP 3.3
Xerographic Connector
Assembly), then go to
step 9.
Go to Step 9.
9 Is the image printed correctly?
Troubleshooting
complete.
Replace the Drum Car-
tridge.
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
