Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-25
Parts List 2.5 Exit Chute
Item Description Part Number
1. Exit Sensor
2. Exit Gear
3. Earth Sensor Spring
4. Exit Bearing
5. Exit Roll Assembly
6. Left Pinch Roll Assembly (REP 2.15) 604K77510
7. Right Pinch Roll Assembly (REP 2.15) 604K77520
8. Full Stack Actuator
9. Full Stack Sensor (REP 2.13) 930W00123
99. Exit Chute Assembly (with 1-5, 8, 9) (REP 2.11) 054K48380
