Xerox Phaser 3610 Service Manual

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-27
Parts List 2.6 MSI
Item Description Part Number
1. MSI In Stopper
2. MSI In Lock
3. Top Frame
4. No Paper Actuator
5. Feed Solenoid (REP 2.14) 121E23570
6. MSI 1 Segment Gear
7. MSI 2 Segment Gear
8. Feed Bearing
9. Arm Lifter
10. Stopper Lifter
11. Feed Spring
12. Feed Gear
13. Lifter Lever
14. Spring
15. Pick Up Holder Assembly (with 16-20) (REP 2.15) 059K78790
16. Pick UpHolder
17. Idler Feeder Gear
18. Feed Roll Assembly (with 19, 20)
19. Rubber Roll
20. Roll Core
21. Feed Shaft
22. Feed Bearing
23. Pick Up Flange
95. MSI Solenoid Assembly (with 5-7) 121E23570
97. Top Frame Assembly (with 1-4) (REP 2.16) 801K57914
