Xerox Phaser 3610

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-29
Parts List 2.7 Bypass Tray
Item Description Part Number
1. Base Tray
2. End Guide
3. MSI Cover
4. Holder
5. MSI Pad
6. Left Side Guide
7. Right Side Guide
8. Label
9. MSI Tray Assembly (with 1-8, 10-20) (Bypass Tray) 050K71290
10. Retard Roll Spring
11. Stopper Spring
12. Lock
13. MSI Mylar Guide
14. Stopper
15. Retard Roll Holder
16. Retard Roll Assembly
17. Friction Clutch Assembly
18. MSI Paper Stopper Spring
19. Side Guide Rack
20. Pinion Gear
96. MSI Frame Assembly (with 1, 2, 4-7, 11-14, 18-20)
98. MSI Retard Roll Assembly (with 10, 15-17) (REP 2.17) 604K78370
99. MSI Cover Kit (with 3, 8)
