Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-35
Parts List 3.3 Toner Dispense
Item Description Part Number
1. CRUM Housing Assembly (with 2, 3)
2. CRUM Connector Assembly
3. CRUM Housing
4. CRUM Spring
5. Dispense Drive Assembly (with 6-8) (REP 4.6) 007K18413
6. Dispense Housing Drive
7. Gear Idler Motor
8. Output Gear
9. Dispense Motor (REP 4.7) 127K52160
10. Xerographic Connector Assembly (REP 3.3) 116K91040
99. CRUM Assembly Kit (with 1, 4) (REP 3.2) 604K77290
