Xerox Phaser 3610

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-51
Parts List 5.4 Electrical
Item Description Part Number
1. Inlet Harness Assembly 100
Inlet Harness Assembly 200
2. Bracket Switch
3. ESS Harness Assembly
4. ESS Power Harness Assembly SFP
5. Harness Assembly LV
6. MCU Harness Assembly 24v
7.
8. OP FDR Harness Assembly
9. FSR Harness Assembly 100
FSR Harness Assembly 200
10. Dispense Motor Harness Assembly
11. Main Motor Harness Assembly
12. Xerographic Harness Assembly CRUM
13. Harness Assembly HV
14. Test Relay Harness Assembly
15. Exit Sensor Harness Assembly
16. Rear Fan Harness Assembly
17. Harness Assembly
18. Drawer Harness Assembly
99. (3610) AC Inlet Kit 100v (With 1, 2)
(3610) AC Inlet Kit 200v (With 1, 2) (REP 5.9)
604K78900
604K78910
99. (3615) AC Inlet Kit 100v (With 1, 2)
(3615) AC Inlet Kit 200v (With 1, 2) (REP 5.9)
604K85630
604K85640
