Xerox Phaser 3610 Service Manual

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-59
Parts List 7.3 Tray 1/Optional Tray 550-Sheet Feeder (3/4)
Item Description Part Number
1. IOT Cassette Assembly (With 2-36,38) 050K71211
2. Plate Bottom CST Mat X
3. Retard Holder Assembly CST (With 4-7)
4. Feed Roll Assembly
5. Friction Clutch
6. Retard Shaft CST
7. Retard Holder CST
8. Right Side Guide Assembly
9. Left Side Guide Assembly
10. Pinion Gear
11. Cover BTM Lock 550
12. Back BTM Lock 550
13. Pinion Gear BTM Lock
14. Gear Lever BTM Lock
15. Lever BTM Lock
16. Gear 40 BTM Lock
17. Spring BTM Lock
18. Spring Lock Pb
19. Actuator Lock Pb L
20.
21. Spring BTM Up 550 A4
22. Retard Spring Holder
23. Retard Spring Cst
24. Rack Left Up Pb 550
25. Housing Base 550
26. Lever Ext End 550
27. End Guide 550
28. Housing End 550
29.
30. Tray Handle 550
31.
Pad Pb
32. Instruction Label- D
33. Instruction Label Ad
34. Tray Label
35. Label
36. Handle Gd Sd
37. Retard Assembly Roll Instruction
38. End Guide Handle
98. Feed Rolls (With 4*3 Pcs) (REP 7.11) 604K11192
99. Retard Roll Assembly Kit (With 3,37) (REP 7.13) 604K78360
100. Dust Cover 848E93660

Xerox Phaser 3610 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Maximum duty cycle	110000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Network ready	Yes
Security algorithms	EAP, EAP-TLS, EAP-TTLS, WPA-PSK, WPA2-PSK
Mobile printing technologies	Apple AirPrint
Internal memory	512 MB
Processor frequency	400 MHz
Maximum internal memory	1024 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper
Paper tray media weight	60 - 216 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet
Optional connectivity	Wireless LAN
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (standby)	52 W
Power consumption (printing)	686 W
Power consumption (PowerSave)	2 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 28 °C
Operating relative humidity (H-H)	20 - 70 %
Product color	Blue, White

Weight and Dimensions

Depth	426 mm
Width	393 mm
Height	315 mm
Weight	13000 g
