Xerox Phaser 3610

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-11
3. Print Info
•Info Page
•Print Settings
3. Scanner Maintenance
•White Balance
–Auto Adjust (FB)
– Auto Adjust (DADF)
• Shading Parameter
– Coeff FB RED
– Coeff FB Green
– Coeff FB Blue
– Coeff FB Grey
–Coeff DADF RED
– Coeff DADF Green
–Coeff DADF Blue
– Coeff DADF Grey
–Target RED
– Target Green
–Target Blue
–Target Grey
• Registration Parameter
–Regi FB Lead
–Regi FB Side
– RegiDADFLead (Front)
– RegiDADFSide (Front)
–RegiDADFLead (Back)
– RegiDADFSide(Back)
– RegiDADFLead (FrontDUP)
• Auto Registration
•Sensor Parameter
– Feed Sensor
•Vertical Scan Mag
–Mag FB Color
–Mag FB Grey
–Mag DADF Color
– Mag DADF Grey
• Test Pattern
–Pattern No.
3. Adjust Touch-
screen...
Printer Diag (3610 / 3615) Fax / Scanner Diag (3615) Panel Diag (3615)
