Xerox Phaser 3610

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-13
5. Test Print
•Pattern IOT
•Gradation ESS
•Ghost Chart ESS
5. Back Up Data
• All Clear
•User Clear
•System Clear
• User & System Clear
•System Data
•Document Clear
5. LED Test
•Services
•job Status
•System
•Energy Saver
•Data
•Error
6. Parameter
•Regi
–SlowScan KtoP
– FastScan SmpBTray
– FastScan SmpBTray1
– FastScan SmpBTray2
(3610)
– FastScan DupBTray
–FastScan DupTray1
–FastScan DupTray2
(3610)
•Life
–Fuser PV
– Fuser Heattime
–Trans Unit PV
–IU PV
–IU Thickness
– Waste Full Count
–Toner Disp Time
–Toner Pixel
– Toner Gas Gauge
•Print
–Print Parameter
6. Complete
• Complete?
6. Brightness Test...
7. RTC Set 7. Display Test...
8. Exit Mode
• Complete Exit
–Exit
8. Adjust Sense of
Touch...
9. Buzzer Test...
Printer Diag (3610 / 3615) Fax / Scanner Diag (3615) Panel Diag (3615)
