Xerox Phaser 3610

Specifications
Phaser 3610, WorkCentre 3615 Service Manual8-18
Print image quality guaranteed area
The print image quality specified in this section is guaranteed in the print image quality guaranteed
area specified in the following table.
Note: *1: Maximum width of 8.66 in. (220mm) for Envelope (DL LEF)
Evaluation Criteria
The print image quality is guaranteed with the Spec. In rate = 90% (g = 90%).
Area definition Specification
Usable Area (maximum paper size) 8.68 (*1) x 14 in. (215.9 x 355.6mm)
Un-printable Area Default: 4.1mm each from four edges of paper
Printable Area
8.18 x 13.68 in. (207.7 x 347.4mm)
8.68 x 14 in. (215.9 x 355.6mm (Edge to edge mode))
Print quality guaranteed Area 8.18 x 13.68 in. (207.7 x 347.4mm)
ZaS06004XA
4.1mm
4.1mm
4.1mm
4.1mm
355.6mm
(14inch)
215.9mm
(8.5inch)
Print image quality
guaranteed area
207.7mm
347.4mm
