Troubleshooting

Phaser 3610, WorkCentre 3615 Service Manual 2-33

050-132

Paper Jam

Open Bypass Tray,

Tray1, Tray2,

Rear Door

and remove paper

Cause:

When Dynamic Jam (cause) was detected:

• 077-106 Exit On Jam

When Static Jam (collateral) was detected:

•Regi Sensor On

FIP 1. 259

050-134

Paper Jam

Open Bypass Tray,

Tray1, and

remove paper

Press OK to start

Cause:

When Dynamic Jam (cause) was detected:

• 071-100 IOT Tray1 Misfeed Jam

• 075-100 MSI Misfeed Jam

FIP 1. 260

050-135

Paper Jam

Pull Out Tray4

Clear Jam. Or

Clear Jam From

Back of Tray.

Press OK to start

Cause:

When Dynamic Jam (cause) was detected:

• 073-101 IOT Path3 SNS On Jam

When Static Jam (collateral) was detected:

• Tray2 Path Sensor On, Tray3 Path Sensor On,

and Tray4 Path Sensor On

FIP 1. 261

050-136

Paper Jam

Pull Out Tray3,4,

Clear Jam. Or

Clear Jam From

Back of Tray3.

Press OK to start

Cause:

When Dynamic Jam (cause) was detected:

• 072-101 IOT Path2 SNS On Jam

When Static Jam (collateral) was detected:

•Tray3 Path Sensor On

FIP 1. 262

050-137

Paper Jam

Pull Out Tray3

Clear Jam. Or

Clear Jam From

Back of Tray.

Press OK to start

Cause:

When Dynamic Jam (cause) was detected:

• 072-102 IOT Option Regi On Jam

When Static Jam (collateral) was detected:

• Tray2 Path Sensor On and Tray3 Path Sensor

FIP 1. 263

Status

Code

(3610)

LCD Message Name/Description of Error FIP

Other manuals for Xerox Phaser 3610

User Guide144 pages

Quick User Guide5 pages

Specifications5 pages

Quick Use Guide5 pages

Hardware Installation Instructions17 pages
