Outboard motor troubleshooting
Trouble code table
To display trouble codes (code number 300 and higher) for the SBW system, connect using the CAN-
Line harness.
*1: Crankshaft position sensor
*2: Fuel pressure sensor (high-pressure fuel pump)
: Indicated
—: Not indicated
Code No. Item YDIS diagnosis
YDIS diagnosis
record
13 Pulser coil *1
15 Engine temperature sensor
17 Knock Sensor 1
19 Battery voltage
20 Knock Sensor 2
23 Air temperature sensor
24 Cam position sensor (EX)
27 Water in fuel filter
29 Air pressure sensor
39 Oil pressure sensor
42 Thermo sensor (P)
43 Thermo sensor (S)
44 Engine shut-off switch —
56 Main power supply
57 Starter magnet power supply
60 Generator system
71 Cam position sensor (S bank IN)
72 Cam position sensor (P bank IN)
73 OCV (S bank)
74 OCV (P bank)
83 PTT sensor
84 PTT buzzer
86 Immobilizer —
112, 113,
114, 115,
116, 117,
119, 123,
138, 141,
142, 143,
144, 145
ETV
124, 125,
126, 127,
128
TPS
