Outboard motor troubleshooting
4-6
146, 147,
148, 149,
150, 153,
154, 155
SPS
156, 157 Engine-R/C communication
160, 161,
162, 163,
164, 165,
166, 167,
168, 169,
170, 171,
172, 173,
174, 175,
176, 177,
178, 179,
180, 181,
183, 184,
186, 187
Remote control system
190 PTT relay
191 PTT relay power
192 Shift actuator power supply
193 VST fuel pump power supply
194 Water pressure sensor
195 Medium pressure fuel pressure sensor *2
196 Fuel system
210 Engine-FuseBox communication
213 EDU power supply 1
214 EDU power supply 2
215 DI fuel pressure sensor (P)
216, 217 DI fuel pressure (P)
218
DI fuel pump (P)
(DI fuel pressure pump P)
219 DI fuel pressure sensor (S)
220, 221 DI fuel pressure (S)
222 DI fuel pump (S)
223 Steering system
224 Steering system–Outboard (SCU)
225 Steering system–Helm (HELM)
Code No. Item YDIS diagnosis
YDIS diagnosis
record
To Next Page
