Camshaft
7-57
14. Install:
• O-ring “1”
•Hose nipple “2”
•Guide (PORT) “3”
• Bracket (PORT) “4”
•Guide (STBD) “5”
• Bracket (STBD) “6”
15. Install:
• Fuel injectors
• Fuel rails
• Direct injection pumps
See “Installing the fuel injector and fuel
rail” (6-20).
• Exhaust joint
See “Installing the exhaust joint” (7-12).
T
R
.
.
Cylinder head cover bolt
1st: 8 N·m (0.8 kgf·m, 5.9 lb·ft)
2nd: 8 N·m (0.8 kgf·m, 5.9 lb·ft)
New
EE
1
2
5
3
4
6
