Propeller and water inlet cover
8-4
2. Tighten:
• Propeller nut
Place a block of wood between the anticavita-
tion plate and the propeller to prevent the pro-
peller from turning, and then tighten the
propeller nut.
3. Install:
• Cotter pin “1”
If the slots in the propeller nut “2” are not
aligned with the cotter pin hole, tighten the
propeller nut until they are aligned.
Propeller nut
80 N·m (8.0 kgf·m, 59 lb·ft)
DD
1
5
4
3
2
1
2
