8-5
Lower unit
Lower unit
A. For X-transom model
B. For U-transom model
C. For E-transom model
D. Except for X-transom model
*. Use white sealant for white-colored units.
572572
LTLT
572572
LTLT
572572
LTLT
572572
LTLT
572572
LTLT
16
5
A
D
A
D
11
10
5
1
2
3
5
ABC
ABC
8
9
4
6
7
11
10
New
12
17
17
13
14
15
13
New
18
47 N
·
m (4.7 kgf
·
m, 35 lb
·ft
)
47 N
·
m (4.7 kgf
·
m, 35 lb
·ft
)
47 N
·
m (4.7 kgf
·
m, 35 lb
·ft
)
47 N
·
m (4.7 kgf
·
m, 35 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
**
Part name
Q
’ty
Remarks
1 Bolt M10
× 60 mm 1
2Washer 1
3Anode 1
4 Bolt M10
× 100 mm 1
5 Bolt M10
× 45 mm 9
6 Bolt M10
× 225 mm 1
7 Bolt M10
× 355 mm 1
8 Bolt M10
× 174 mm 1
9 Bolt M10
× 299 mm 1
10 Nut M10 8
11 Washer 8
12 Lower unit 1
13 Dowel 2
14 Rubber seal 1
15 Plate 1
16 O-ring 1
17 Backup ring 2
18 O-ring 1
