Rectifier/regulator continuity table (F400A/FL400A/XF400A)
“j” All terminals OL
“k”
“j” 0.22–0.43
Except for “j” OL
“l”
“j” 0.22–0.43
Except for “j” OL
“m”
“j” 0.22–0.43
Except for “j” OL
“n”
j 0.48–0.69
“k”, “l”, “m” 0.22–0.43
Except for “j”, “k”, “l”, and “m” OL
“o” All terminals OL
“p” All terminals OL
“q”
“p” 0.22–0.43
Except for “p” OL
“r”
“p” 0.22–0.43
Except for “p” OL
“s”
“p” 0.22–0.43
Except for “p” OL
“t”
“p” 0.48–0.69
“q”, “r”, and “s” 0.22–0.43
Except for “p”, “q”, “r”, and “s” OL
Rectifier/regulator for continuity
Tester probe
Display value (reference data)
(+) (–)
