Rectifier/regulator continuity table (F450A/FL450A/XF450A)
A-22
Rectifier/regulator continuity table (F450A/FL450A/XF450A)
OL: Indicates an overload
Rectifier/regulator for continuity
Tester probe
Display value (reference data)
(+) (–)
“a”
“e”, “f” and “g” 1.83 V
“h” 1.35 V
“n” 1.89 V
“t” 1.90 V
“V” 1.82 V
Except for “e”, “f”, “g”, “h”, “n”, “t” and “v” OL
“b”
“c” 0.08 mV
Except for “c” OL
“c”
“b” 0.08 mV
Except for “b” OL
“d” All terminals OL
“e” All terminals OL
“f” All terminals OL
“g” All terminals OL
R W W L R
u
a
v
b
e
g
f
k
m
l
q
s
r
d
h
c
j
n
i
p
t
o
1
6
3
4
1
23456
