A-23
Rectifier/regulator continuity table (F450A/FL450A/XF450A)
“h”
“e”, “f” and “g” 0.48 V
“k”, “l”, “m”, “q”, “r” and “s” 1.08 V
“n” and “t” 0.61 V
“v” 0.47 V
Except for “e”, “f”, “g”, “k”, “l”, “m”, “n”,
“q”, “r”, “s”, “t” and “v”
OL
“i” All terminals OL
“j” All terminals OL
“k” All terminals OL
“l” All terminals OL
“m” All terminals OL
“n”
“e”, “f” and “g” 1.17 V
“h” 0.69 V
“k” and “m” 0.48 V
“l” 0.47 V
“q” and “r” 1.77 V
“s” 1.78 V
“t” 1.30 V
“v” 1.16 V
Except for “e”, “f”, “g”, “h”, “k”, “l”, “m”,
“q”, “r”, “s”, “t” and “v”
OL
“o” All terminals OL
“p” All terminals OL
“q” All terminals OL
“r” All terminals OL
“s” All terminals OL
“t”
“e”, “f” and “g” 1.17 V
“h” 0.69 V
“k” and “m” 1.78 V
“l” 1.77 V
“n” 1.30 V
“q” and “s” 0.48 V
“r” 0.47 V
“v” 1.16 V
Except for “e”, “f”, “g”, “h”, “k”, “l”, “m”,
“n”, “q”, “r”, “s” and “v”
OL
Rectifier/regulator for continuity
Tester probe
Display value (reference data)
(+) (–)
