R5905948 /12 Event Master Devices240
All Trans button
This button transitions selected Destinations from Preview to Program in the amount of time set in the
transition rate. The transition rate is declared in frames as a compared to the System Native Rate defined on
the Configuration menu. By default, the System Native Rate is set to 59.94 frames per second, so a transition
rate of 30 would transition the look from Preview to Program in about ½ second.
Four transition types are available: Linear, S-Curve, Logarithmic and Exponential.
Image 6-101
CUT button
Pressing the CUT button immediately replicates the “look” on Preview to Program.
6.33 Cue Menu
General
The Cue menu is the module used to create Cues and to add Presets, External Device commands, and UI
functions such as All Trans and Cut to those Cues. The Cue menu also allows the user to play, pause, or stop
a Cue.
Description
The Cue menu has four main areas, each of which contains information or controls.
Image 6-102: Cue menu
1. Menu navigation bar—The menu navigation bar allows the user to choose from among the available
menus: Configuration, Programming, Cue, Multiviewer, Controller, or Settings.
2. Command resource area—The command resource area contains tabs for the Dest Groups, Custom (UI
functions), Devices, and Presets available for Cues.
3. Cue Workspace area—The Cue Workspace area allows the user to add a limited list of Actions and to
assign names wait times commands, and parameters to the Actions in each Cue.
4. Adjustment area—The adjustment area allows the user to add, delete, lock, unlock, and rename Cues.
The adjustment area also allows the user to play, pause, or stop a Cue.
/ (Play / Pause) and (Stop) buttons.
