4K / UHD 4 1 SMPTE 424M
SMPTE 2048-2
Image mapping: Quadrants
3840x2160 @ 50/59.94/60 as 4x 3G-SDI
4096x2160 @ 50/59.94/60 60 as 4x 3G-SDI
Level A and B supported
4K / UHD 4 1 SMPTE ST 425-5 Image mapping: 2 Sample Interleave
Subdivision (2SI)
3840x2160 @ 23.98/24/25/29.97/30 as 4x HD-
SDI
4096x2160 @ 23.98/24/25/29.97/30 as 4x HD-
SDI
3840x2160 @ 50/59.94/60 as 4x 3G-SDI
4096x2160 @ 50/59.94/60 60 as 4x 3G-SDI
Level A and B supported
DisplayPort
Digital display interface developed by the Video Electronics Standards Association (VESA). This
royalty-free interface is primarily used to connect a video source to a display device such as a
computer monitor, though it can also be used to transmit audio, USB, and other forms of data.
VESA designed it to replace VGA, DVI, and FPD-Link. Backward compatibility to VGA and DVI by
using active adapter dongles enables users to use DisplayPort fitted video sources without
replacing existing display devices.
HDMI
HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring
uncompressed video data and compressed/uncompressed digital audio data from a HDMI-
compliant device ("the source device") to a compatible computer monitor, video projector, digital
television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
SDI
Serial Digital Interface (SDI) is a serial link standardized by the Society of Motion Picture and
Television Engineers (SMPTE). SDI transmits uncompressed digital video over 75-ohm coaxial
cable within studios, and is seen on most professional video infrastructure equipment.
4.14 Expansion Link Card
About Expansion link
When event requirements exceed the capacity of a single unit in terms of input, output, or number of layers,
multiple Event Master processors can be linked together through the Expansion Link cards.
CXP
CXP is a copper connector system specified by the InfiniBand Trade Association. It provides twelve
10 Gbit/s links suitable for single 100 Gigabit Ethernet, three 40 Gigabit Ethernet channels, or
twelve 10 Gigabit Ethernet channels or a single Infiniband 12× QDR link. The connector has 4 rows,
each of 21 pin, total 84 pins.
[Note 1]: The C is the Roman numeral for 100.
General
The Link card has 2 CXP connectors which can support up to 12 10-Gbit channels.
The figure below illustrates the Link card's rear panel connectors:
Hardware orientation
To Next Page
