Barco Event Master E2 Series User Manual

R5905948 /12 Event Master Devices546
A.16 Specifications of the DP/HDMI input card (Gen
1)
R9004744 – DP/HDMI input card specifications
HDCP DisplayPort 1.1 supports HDCP version 1.3. HDMI 1.4 supports HDCP
version 1.4.
Capacity DP 1.1 input and HDMI 1.4 input support up to 4x 1200p@60, or 1x
4K@60p/ UHD per card (dual cable).
DisplayPort Input Up to RGB, 4:4:4, 12 bit; or YCbCr, 4:4:4, 12 bit; (up to 300 Mpix/s)
HDMI Input Up to RGB, 4:4:4, 12 bit; or YCbCr, 4:4:4, 12 bit; (up to 297 Mpix/s)
A.17 Specifications of the HDMI output card (Gen
1)
R9004743 – HDMI output card specifications
HDCP HDMI 1.4 supports HDCP version 1.4.
Capacity Supports up to 4x 1200p@60 4:4:4, 2x 4K/UHD@30 4:4:4, or 1x 4K@60p/
UHD 4:4:4 per card (dual cable).
HDMI Output Up to RGB, 4:4:4, 12 bit; or YCbCr, 4:4:4, 12 bit; (up to 297 Mpix/s)
A.18 Specifications of the HDMI 2.0 quad input
card (Gen 2)
R9004791 – HDMI 2.0 quad input card specifications
HDCP Supports HDCP 2.2 content Type 0 and Type 1 when a 2.2 compliant
output is available (backwards-compatible with HDCP 1.x).
Capacity 2x UHD@60p (HDMI 2.0) or 4x WQXGA@60p (HDMI1.4a) inputs per card
(when used in a dual capacity input slot)
Input UHD@60p 8-bit 4:4:4 or UHD@60p 10-bit 4:2:2 – up to 600 Mpix/s
A.19 Specifications of the HDMI 2.0 quad output
card (Gen 2)
R9004792 – HDMI 2.0 quad output card specifications
HDCP Supports HDCP 2.2 content when an HDCP 2.2 compliant signal chain is
present (backwards-compatible with HDCP 1.x).
Capacity 2x UHD@60p or 4x high-speed (Dual Link Type) outputs per card
Output
• Supports up to UHD@60p 12-bit 4:2:2 per card.
• Supports 4x 1200p@60 4:4:4, 4x 4K/UHD@30 4:4:4, or 2x 4K@60p/
UHD 4:4:4 per card.
• Up to 600 Mpix/s
