R5905948 /12 Event Master Devices70
4K / UHD 4 1 SMPTE 292M
SMPTE 2048-2
Image mapping: Quadrants
3840x2160 @ 23.98/24/25/29.97/30 as 4x HD-
SDI
4096x2160 @ 23.98/24/25/29.97/30 as 4x HD-
SDI
4K / UHD 4 1 SMPTE 424M
SMPTE 2048-2
Image mapping: Quadrants
3840x2160 @ 50/59.94/60 as 4x 3G-SDI
4096x2160 @ 50/59.94/60 60 as 4x 3G-SDI
Level A and B supported
4K / UHD 4 1 SMPTE ST 425-5 Image mapping: 2 Sample Interleave
Subdivision (2SI)
3840x2160 @ 23.98/24/25/29.97/30 as 4x HD-
SDI
4096x2160 @ 23.98/24/25/29.97/30 as 4x HD-
SDI
3840x2160 @ 50/59.94/60 as 4x 3G-SDI
4096x2160 @ 50/59.94/60 60 as 4x 3G-SDI
Level A and B supported
DisplayPort
Digital display interface developed by the Video Electronics Standards Association (VESA). This
royalty-free interface is primarily used to connect a video source to a display device such as a
computer monitor, though it can also be used to transmit audio, USB, and other forms of data.
VESA designed it to replace VGA, DVI, and FPD-Link. Backward compatibility to VGA and DVI by
using active adapter dongles enables users to use DisplayPort fitted video sources without
replacing existing display devices.
HDMI
HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring
uncompressed video data and compressed/uncompressed digital audio data from a HDMI-
compliant device ("the source device") to a compatible computer monitor, video projector, digital
television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
SDI
Serial Digital Interface (SDI) is a serial link standardized by the Society of Motion Picture and
Television Engineers (SMPTE). SDI transmits uncompressed digital video over 75-ohm coaxial
cable within studios, and is seen on most professional video infrastructure equipment.
4.9 Quad Channel DisplayPort 1.2 Output Card
General
The quad channel DisplayPort 1.2 output card has four 20-pin DisplayPort connectors that can provide a
DisplayPort signal.
The figure below illustrates the DisplayPort 1.2 output card’s rear panel connectors:
Hardware orientation
