R5905948 /12 Event Master Devices 93
The unit begins to reset. This takes about two minutes.
4. Remove the USB drive.
Once the system resets, all the Inputs, Outputs, Destinations Presets, etc. from the simulated unit will have
been transferred to the live unit.
The icons from the simulated unit do not transfer to the live unit and must be recreated.
If the Multiviewer configurations are not transferred, they must be recreated.
5.9 System menu > Ethernet
General
The Ethernet submenu allows the user to view and change certain Ethernet settings.
Image 5-17
Using this menu, you can:
• Query the DHCP server for a valid IP address, or turn off this feature.
• Set a static IP address for the Event Master unit, along with a subnet mask and gateway. This feature is
available only if DHCP is turned Off.
• View the unit’s IP address.
If there is no internet connection, or if a DHCP server has not been found, the IP address is
000.000.000.000. In this case, the system ignores the Ethernet port.
• View the Media Access Control (MAC) address of the unit’s Ethernet port.
Query the DHCP server
In the Ethernet submenu, the default setting for DHCP is On. When DHCP is turned on, the system
automatically queries the DHCP server for a valid IP address. If the unit receives an IP address, that address
is displayed in the Ethernet submenu.
It can take several seconds to obtain an address from the server. During this time, the SEL button
remains lit.
When DHCP is off, you can manually enter a static IP address, along with a subnet mask and gateway, in the
Set Static IP submenu. Consult your network administrator for a valid IP address, subnet mask and gateway.
Setting a static IP Address
When a DHCP server is not available, you can set the Event Master unit’s IP address, using the Set IP
submenu shown in the following illustration.
Image 5-18: Set IP Submenu (sample)
Front Panel Menu orientation
