R5905948 /12 Event Master Devices 387
The EMI filter is no longer needed, and it can be removed.
14.3 Spare Parts Serviceable by All Users
E2 Spare Parts list
P/N
Description
Comments
R767241K * VFD Display assembly
R767246K * VFD Filter
R767260K * Front Panel board
R767261K System Power board
R767263K * Heatsink fan One for each Input, Output, Link and VPU card
R767264K * CPU module
R767265K * Motherboard Heatsink &
Fan kit
R767268K Front Rack ears Includes hardware for both sides
R767269K Cable Kit set Kit Contains:
• 1x VFD-to-System board cable
• 2x Fan tray-to-System board cables
• 1x Genlock-to-System flat cable
• 1x Front Panel Keyboard-to-System flat cable
• 1x RJ45-to-System CAT5 Ethernet cable
• 1x USB-to-System 5-pin cable
R767270K 1RU fan tray The fans are not available separately
R767271K
(Obsolete)
3RU fan tray The fans are not available separately — will be replaced by
R767280
R767273K * Rear Rack ears (Connector
protector)
Includes hardware for both sides
R767275K * Solid-State Memory
R767280K * 3RU fan tray The fans are not available separately — will replace
R767271K
R9004740 * DVI Input Board
R9004741 * SDI Output Board
R9004742 * SDI Input Board
R9004743 * HDMI Output Board
R9004744 * DP/HDMI Input Board
R9004745 * DVI Output Board Not available in release 1
R9004746 * Link Card Board
R9004747 VPU Board Internal board
R9004748 Genlock Board
R9004750 * Link/CXP Cable
R9004765 * Quad DP 1.2 Output Board
R9004769* Power Supply (PS) One PS only. System accepts two power supplies.
R9004785 * Tri-Combo Input Board
R9004786 * Tri-Combo Output Board
R9004791 * Quad HDMI Input Board
R9004792 * Quad HDMI 2.0 Output
Board
R9004793 * Quad DP 1.2 Input Board
R9801120* Motherboard Battery Kit
(*) common between E2 and S3.
E2 Maintenance
