Barco Event Master E2 Series - A.2 Specifications of E2 Jr.

R5905948 /12 Event Master Devices 535
Control
• Event Master screen management software for PC or MAC
• Event Master controllers
• WebUI
• Ethernet RJ-45, 1000/100/10 Mbps autosense
Serviceability
• Field-serviceable I/O and processing cards (not hot-swappable)
• Hot-swappable dual-redundant power supplies
Noise level Max 52.9 dB avg. Fans at 100%. Fan speed is software-managed based
on operating temperature. Reference ISO 7779.
Dimensions
• Height: 17.8 cm (7.0 in) – 4 RU rackmount
• Width: 43.2 cm (17 in) without chassis handles, 48.3 cm (19 in) with
chassis handles attached
• Depth: 56.9 cm (22.4 in) from front panel to rear panel, 62.2 cm (24.5 in)
overall
Weight 31 kg / 68 lbs
Power
• Input power: 100–240 VAC 50/60Hz 826W
• Ships with dual-redundant, hot-swappable power supplies
Warranty 3 years parts and labor
Environmental temperature 0–40° C / 32–104° F
Environmental humidity 0–95% non-condensing
A.2 Specifications of E2 Jr.
R9004777 – E2 Jr. Specifications
Model NGS-4U
Live effects canvas
• Up to 10 Megapixels PVW/PGM
• 20 Megapixels PGM only
• 40 Megapixels @30p and PGM only
Video inputs 16 inputs via 4 input cards (Event Master Series 1 cards)
• Up to 4 x 4K inputs - each input card supports up to 1 x 4K@60p
• 4 x SD/HD/3G SDI
• 6 x HDMI 1.4a (297 Mpix/sec max)
• 6 x DisplayPort 1.1 (300 Mpix/sec max)
Video outputs 10 outputs via 3 output cards (Event Master Series 1 cards)
• Up to 2 x 4K outputs - each output card supports up to 1 x 4K@60 p
• 4 x SD/HD/3G SDI
• 4 x HDMI 1.4a (297 Mpix/sec max)
• 2 x HDMI 1.4a for Multiviewer (297 Mpix/sec max)
Genlock Analog reference input/loop on BNC connectors; bi-level and blackburst at
SD and tri-level at HD
S3D Sync: 4x input Din connector, 2x output Din connector
Program output Up to 8 program outputs configurable as single screens or tiled/blended
widescreens (preview and Multi-Viewer not available in all configurations)
• Configurable for up to 8x 2048X1200@60 or up to 2x 4096x2400@60
• Independent edge blending/feathering control for all four sides
Program scaling (PiP/Key)
layers
• Native resolution background mixer per output screen
• Independent layer transitions or full Preview/Program transition
Specifications
