How to install the Front Panel Knob
To install the Front Panel Knob follow the same procedure in the reverse order.
15.11 Front Panel Mount
Flow chart
Image 15-22
Necessary tools
1 x Phillips Screwdriver #2
How to remove the Front Panel Mount
1. Turn the Front Cover over and remove the four screws (4-40X.25) that secure the control panel mount to the
front panel.
Image 15-23
