A.24 Specifications of standard connections
Standard connection specifications
DisplayPort (DP)
• Per DP 1.1a specification
• On DP connector
• Formats up to 2,560 × 1,600 at 60 Hz and 3,840 × 1,200 at 60 Hz (30 bits)
• 4K/UHD supported:
- 3,840 × 2,160/23.98/24/25/29.97/30 via 1x DP, 2x DP (L and R half), or
4x DP (quadrants)
- 3,840 × 2,160/50/59.94/60 via 2x DP (L and R half) or 4x DP (quadrants)
- 4,096 × 2,160/23.98/24/25/29.97/30 via 1x DP, 2x DP (L and R half) or 4x
DP (quadrants)
- 4,096 × 2,160/50/59.94/60 via 2x DP (L and R half) or 4x DP (quadrants)
- 4,096 × 2,400/23.98/24/25/29.97/30/50/59.94/60 via 2x DP (L and R half)
or 4x DP (quadrants)
• EDID version 1.3 compatible
• HDCP version 1.4 compatible
DVI
• Per DVI 1.0 specification
• DVI Digital video on DVI-I connector
• All single-link DVI formats up to 165 MHz
• All dual-link DVI formats up to 330 MHz
• Maximum H Active: 4,096; Maximum V Active: 3,072
• 4K/UHD Supported:
- 3,840 × 2,160/23.98/24/25/29.97/30 input via 1x DVI-DL, 2x DVI-SL (L
and R half) or 4x DVI-SL (quadrants)
- 3,840 × 2,160/50/59.94/60 input via 2x DVI-DL (L and R half) or 4x DVI-
SL (quadrants)
- 4,096 × 2,160/23.98/24/25/29.97/30 input via 2x DVI-SL (L and R half) or
4x DVI-SL (quadrants)
- 4,096 × 2,160/50/59.94/60 input via 2x DVI-DL (L and R half) or 4x DVI-
SL (quadrants)
- 4,096 × 2,400/23.98/24/25/29.97/30 input via 2x DVI-SL (L and R half) or
4x DVI-SL (quadrants)
- 4,096 × 2,400/50/59.94/60 input via 2x DVI-DL (L & R half) or 4x DVI-SL
(quadrants)
• EDID version 1.3 compatible
• HDCP version 1.4 compatible
