R5905948 /12 Event Master Devices 543
A.9 Specifications of EC-200
R9004771 – EC-200 Specifications
Features
• Robust Linux version of Event Master Toolset – same user interface
used on Mac and PC
• Onboard PC running Linux to support a purpose-built version of Event
Master toolset, enabling stand-alone usage
• Full control over the Event Master Series switchers
• Simultaneous connection of multiple controllers, GUI interfaces, and
processors supported on same network. (Redundant backups of
control)
• 2 x internal 15.6-inch wide screen full HD (1,920x1,080) touchscreens
with 10 point multi touch
• 2 x external monitors or touchscreens supported*
• High-resolution T-Bar for manual transitions
• 36 user-assignable buttons with customizable LCD labels
• Dedicated Background layer button
• 8 dedicated Layer selection buttons with multi-page functionality (shift
pages for destinations with 9 or more layers)
• 12 user-definable Destination buttons with multi-page functionality
(easily supports all the available destinations)
• Dedicated buttons for transition, live switching, modifying program,
transitions, etc.
• 5 rotary encoders with wheels for ergonomic pip control and rapid
placement of resources
• 12 LCD Contextual Display Buttons to support the Syntax Programmer
• Tri-axis backlit trackball (based on function), with a very smooth rotary
encoder for the third axis and 4 buttons for cursor and position control
• 2 separate gigabit Ethernet network interface connections, one for
Primary system control, and one for supplemental network control
(additional IP address range and mode)
• Internal Solid State Hard drive
• 5 USB ports for additional accessories such as external touchscreens,
mouse, keyboard, thumbdrive, etc.
• Script lights, feedback LEDs, and integrated work lights – all dimmable
• Dust cover included
• Custom road case included
Connectivity
• Controls multiple Event Master Series systems, including E2 and S3–4K
• Allows for an external control system to interact over a separate
network interface
• Two additional DVI outputs for monitors to increase workspace
• Auto-ranging mains input (90-250VAC)
• External pointing device and Keyboards supported over USB
Dimensions (HxWxD) 244.34 x 901.19 x 575.36 mm (9.62 x 35.49 x 22.65 inches)
Weight 20.41 kg (45 lbs)
Temperature 0–35° C / 32–95° F
Humidity 0–95% non-condensing
*Note The EC-200 DVI-D monitor connections do not support analog output.
Digital displays or digital to analog converters are required.
