R5905948 /12 Event Master Devices482
Image 15-65
Note: It could be necessary to release the cable tie that maintain the fan power cable in place.
How to install Side Support Plate
To install the Side Support Plate follow the same procedure in the reverse order.
There are key holes cut into the bottom of the Side Support Plate which will make installation much
easier. See detail on the previous drawing.
15.27 Link Card Interposer
Flow chart
Image 15-66
S3 Maintenance
