R5905948 /12 Event Master Devices 539
• Output color correction
Still stores Up to 100 HD or 25 UHD, depending on the import file size.
Layer effects
• Borders (hard, soft, halo) and drop shadows
• Color effects
• Strobe, H&V flip
• Luma, chroma and Cut/Fill keys (not all modes support keying)
• PIP moves via Keyframes
Multiviewer
• Flexible user-definable layouts
• Monitor all Inputs and Outputs, including Preview and Aux
• Two outputs
• Dedicated hardware same as E2 Event Master processors
Expandability
• Easily expandable for larger display applications via non-proprietary
links
• Link units to increase available Inputs and Outputs for larger tiled/
blended widescreen applications
• Expansion via simple linking – up to 8 chassis
HDCP HDCP compliance determined by installed cards.
Control
• Event Master screen management software for PC or MAC
• Event Master controllers
• WebUI
• Ethernet RJ-45, 1000/100/10 Mbps autosense
Serviceability
• Field-serviceable I/O and processing cards (not hot-swappable)
• Hot-swappable dual-redundant power supplies
Noise level Max 51.3 dB avg. Fans at 100%. Fan speed is software-managed based
on operating temperature. Reference ISO 7779.
Dimensions
• Height: 13.26 cm (5.22 in) – 3 RU rackmount
• Width: 43.2 cm (17 in) without chassis handles, 48.3 cm (19 in) with
chassis handles attached
• Depth: 54 cm (21.33 in) overall
Weight 21.3 kg / 47 lbs
Power
• Input power: 100–240 VAC 50/60Hz 826W
• Ships with single power supply. Optional Dual-redundant, hot-
swappable power supplies available as upgrade.
Warranty 3 years parts and labor
Environmental temperature 0–40° C / 32–104° F
Environmental humidity 0–95% non-condensing
A.5 Specifications of S3–4K Jr.
R9004778 – S3–4K Jr. Specifications
Model NGS-3U
Live effects canvas
• Up to 10 Megapixels PVW/PGM
• 20 Megapixels PGM only
Video inputs 8 HD inputs via 2 input cards (Event Master Series 1 cards)
• Up to 2 x 4K inputs – each input card supports up to 1 x 4K@60p
• 4 x SD/HD/3G SDI
