R5905948 /12 Event Master Devices540
• 2 x HDMI 1.4a (297 Mpix/sec max)
• 2 x DisplayPort 1.1 (300 Mpix/sec max)
Video outputs 8 HD outputs via 2 output cards (Event Master Series 1 cards)
• Up to 1 x 4K outputs – each output card supports up to 1 x 4K@60p
• 4 x HDMI 1.4a (297 Mpix/sec max)
• 2 x HDMI 1.4a for Multiviewer (297 Mpix/sec max)
(4 x HDMI 1.4a when used as standard output card)
Genlock Analog reference input/loop on BNC connectors; bi-level and blackburst at
SD and tri-level at HD
S3D Sync: 4x input Din connector, 2x output Din connector
Program output 4 program outputs configurable as single screens or tiled/blended
widescreens
• Configurable from 4 x 2048X1200@60 max to 1 x 4096x2400@60 max
• Independent edge blending/feathering control for all four sides
Program scaling (PiP/Key)
layers
• Native resolution background mixer per output screen
• Independent layer transitions or full Preview/Program transition
• Flexible layer allocation – 2 mixable or 4 single scalable PIP/key layers
assignable to any Program output screen
Scaled Aux outputs
• User-definable from 4 x 2048x1200@60 to 1 x 4K@60
• All outputs can be defined as Aux destinations for a total of 8 Aux
outputs
• Output color correction
Still stores Up to 100 HD or 25 UHD, depending on the import file size.
Layer effects
• Borders (hard, soft, halo) and drop shadows
• Color effects
• Strobe, H&V flip
• Luma, chroma and Cut/Fill keys (not all modes support keying)
• PIP moves via Keyframes
Multiviewer
• Flexible user-definable layouts
• Monitor all Inputs and Outputs, including Preview and Aux
• Two outputs
• Dedicated hardware same as E2 Event Master processors
Expandability Linking is available as an upgrade option.
HDCP HDCP compliance determined by installed cards.
Control
• Event Master screen management software for PC or MAC
• Event Master controllers
• WebUI
• Ethernet RJ-45, 1000/100/10 Mbps autosense
Serviceability
• Field-serviceable I/O and processing cards (not hot-swappable)
• Hot-swappable dual-redundant power supplies (optional)
Noise level Max 51.3 dB avg. Fans at 100%. Fan speed is software-managed based
on operating temperature. Reference ISO 7779.
Dimensions
• Height: 13.26 cm (5.22 in) – 3 RU rackmount
• Width: 43.2 cm (17 in) without chassis handles, 48.3 cm (19 in) with
chassis handles attached
• Depth: 54 cm (21.33 in) overall
Weight 21.3 kg / 47 lbs
Power
• Input power: 100–240 VAC 50/60Hz 700W
Specifications
