R5905948 /12 Event Master Devices542
Serviceability Field-serviceable I/O and processing cards (not hot-swappable)
Noise level 37 dBA Nominal / 45 dBA Max Fan speed is software managed based on
operating temperature. Reference ISO 7779.
Dimensions
• Height: 4.37 cm (1.72 in) 1 RU rackmount
• Width: 48.41 cm (19.06 in), including rackmount
• Depth: 40.41 cm (15.91 in)
Weight 5.53 kg / 12.2 lbs
Power Input power: 100–240 VAC 50/60Hz 125W
Warranty 3 years parts and labor
Environmental temperature 0–40° C / 32–104° F
Environmental humidity 0–95% non-condensing
A.7 Specifications of EC-30
R9004783 – EC-30 Specifications
Connectivity USB connection from Event Master Toolset host computer (OSX or
Windows 7 and higher)
Dimensions (HxWxD) 105.4 x 465.6 x 321 mm (4.15 x 18.33 x 12.63 inches)
Weight 3.18 kg (7 lbs)
A.8 Specifications of EC-50
R9004772 – EC-50 Specifications
Connectivity USB connection from Event Master Toolset, from a control computer DVI
input for touchscreen monitor
Dimensions (HxWxD) 244.34 x 511.56 x 610.05 mm (9.62 x 20.14 x 24.02 inches)
Weight 12.33 kg (27.2 lbs)
