Dest sets Transition Time of the Destination, and Layer sets the Transition Time of the Layer in frames based
on the System Native Rate.
Syntax for TIME is:
• DEST # TIME # ENTER will set the Transition time of # frames to Destinations # and add Destination # to
any other selected Destinations for further actions.
• DEST 1 + 5 TIME 60 ENTER will set the Transition time of 60 to Destinations 1 and 5, and add Destination
1 and 5 to any other selected Desalinations for further actions.
• LAYER 1 + 4 TIME 120 ENTER will set the Layer Transition time of 120 to Layer 1 and 4, and add
Destinations 1 and 4 to any other selected Destinations for further actions.
12.14 Additional direct access and functionality
Help Error
Image 12-16
At present, the Help Error button has no functionality assigned to it, and it is reserved for future use.
Layout
Image 12-17
The Layout function button allows for selection and recall of layouts where applicable.
Multi-viewer, Console Buttons and Programming page layouts are currently implemented.
To select a Layout use syntax like:
• LAYOUT 1 [Contextual Button] ENTER will recall Layout 1.
The same number of layouts is available as in the GUI. Layout changes also act as they do in the GUI.
When a layout is selected, changes are recalled for that layout in real time, automatically.
Pressing Layout button will populate the Smart Displays with:
Contextual
Button
Display Description
CD1 MVR LAYOUT MVR (CD1) 1 or 2 or 3 or 4 ENTER will recall Layout 1 – 4
respectively into the Multi-viewer
CD2 Program LAYOUT Program (CD 2) 1 or 2 or 3 or 4 ENTER will recall Layout 1 – 4
respectively into the Programming Window.
The Programming page can have up to ten layouts.
CD3 Console LAYOUT Console (CD 3) 1 or 2 or 3 or 4 ENTER will Recall Layout 1 – 4
respectively into the Assign Buttons.
Screens
Image 12-18
The Screens button is used to change the active top menu page in the displays of the controller. There are
controls for both internal displays (and for one external display on the EC-210).
