Barco Event Master E2 Series User Manual

R5905948 /12 Event Master Devices 65
HDMI specifications
• HDMI per 1.4a specifications
• Supported format:
- formats up to 2,560x1,600@60 and 3,840x1,200@60 (30 bits)
- 4K/UHD Supported:
◦ 3,840x2,160/ 23.98/24/25/29.97/30 input via 1x HDMI, 2x HDMI (L and R half) or 4x HDMI
(quadrants)
◦ 3,840x2,160/ 50/59.94/60 input via 2x HDMI (L and R half) or 4x HDMI (quadrants)
◦ 4,096x2,160/ 23.98/24/25/29.97/30 input via 1x HDMI, 2x HDMI (L and R half) or 4x HDMI
(quadrants)
◦ 4,096x2,160/ 50/59.94/60 input via 2x HDMI (L and R half) or 4x HDMI (quadrants)
• EDID version 1.3 compatible
• HDCP version 1.4 compatible
DisplayPort specifications
• DisplayPort per 1.1a specifications
• Supported format:
- formats up to 2,560x1,600@60 and 3,840x1,200@60 (30 bits)
- 4K/UHD Supported:
◦ 3,840x2,160/ 23.98/24/25/29.97/30 via 1x DP, 2x DP (L and R half) or 4x DP (quadrants)
◦ 3,840x2,160/ 50/59.94/60 via 2x DP (L and R half) or 4x DP (quadrants)
◦ 4,096x2,160/ 23.98/24/25/29.97/30 via 2x DP (L and R half) or 4x DP (quadrants)
◦ 4,096x2,160/ 50/59.94/60 via 2x DP (L and R half) or 4x DP (quadrants)
• EDID version 1.3 compatible
• HDCP version 1.3 compatible
HDMI
HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring
uncompressed video data and compressed/uncompressed digital audio data from a HDMI-
compliant device ("the source device") to a compatible computer monitor, video projector, digital
television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
DisplayPort
Digital display interface developed by the Video Electronics Standards Association (VESA). This
royalty-free interface is primarily used to connect a video source to a display device such as a
computer monitor, though it can also be used to transmit audio, USB, and other forms of data.
VESA designed it to replace VGA, DVI, and FPD-Link. Backward compatibility to VGA and DVI by
using active adapter dongles enables users to use DisplayPort fitted video sources without
replacing existing display devices.
4.6 Quad Channel DisplayPort 1.2 Input Card
General
The quad channel DisplayPort 1.2 input card has four 20-pin DisplayPort connectors that can accept a
DisplayPort signal.
Upgrade the E2/S3/EX software version to 6.2 or higher before using the quad-channel DisplayPort
1.2 input card.
The figure below illustrates the DisplayPort 1.2 input card’s rear panel connectors:
Hardware orientation
