A.1 Specifications of E2
R9004799 – E2 Specifications
Model NGS-4U
Live effects canvas
• Up to 20 Megapixels PVW/PGM
• 40 Megapixels PGM only
• 80 Megapixels @30p and PGM only
Video inputs 32 inputs via 8 input cards (Event Master Series 1 cards)
• Up to 8 x 4K inputs - each input card supports up to 1 x 4K@60p
• 12 x SD/HD/3G SDI
• 10 x HDMI 1.4a (297 Mpix/sec max)
• 10 x DisplayPort 1.1 (300 Mpix/sec max)
Video outputs 14 outputs via 4 output cards (Event Master Series 1 cards)
• Up to 3 x 4K outputs - each output card supports up to 1 x 4K@60 p
• 4 x SD/HD/3G SDI
• 8 x HDMI 1.4a (297 Mpix/sec max)
• 2 x HDMI 1.4a for Multiviewer (297 Mpix/sec max)
Genlock Analog reference input/loop on BNC connectors; bi-level and blackburst at
SD and tri-level at HD
S3D Sync: 4x input Din connector, 2x output Din connector
Program output Up to 16 program outputs configurable as single screens or tiled/blended
widescreens (preview and Multi-Viewer not available in all configurations)
• Configurable for up to 16x 2048X1200@60 or up to 4x 4096x2400@60
• Independent edge blending/feathering control for all four sides
Program scaling (PiP/Key)
layers
• Native resolution background mixer per output screen
• Independent layer transitions or full Preview/Program transition
• Flexible layer allocation – 16 mixable or 32 single scalable PIP/key
layers assignable to any Program output screen
Scaled Aux outputs
• User definable for up to 16 x 2048x1200@60 or up to 4 x 4K@60
• All outputs can be defined as Aux destinations for a total of 16 Aux
outputs
• Output color correction
(Preview and Multiviewer not available in all configurations.)
Still stores Up to 100 HD or 25 UHD, depending on the import file size.
Layer effects
• Borders (hard, soft, halo) and drop shadows
• Color effects
• Strobe, H&V flip
• Luma, chroma and Cut/Fill keys (not all modes support keying)
• PIP moves via Keyframes
Multiviewer
• Flexible user-definable layouts
• Monitor all Inputs and Outputs, including Preview and Aux
• Two outputs
Expandability
• Easily expandable for larger display applications via non-proprietary
links
• Link units to increase available Inputs and Outputs for larger tiled/
blended widescreen applications
• Expansion via simple linking – up to 8 chassis
• E2 ships with the ability to link 8 chassis for expansion.
HDCP HDCP compliance determined by installed cards.
